Model |
Length (cm) |
Width (cm) |
Height (cm) |
Volume (cm³) |
Weight (g) |
|---|---|---|---|---|---|
|
Diamond M5 |
6 |
3.60 |
2.40 |
51.840 |
29 |
|
Diamond M6 |
6.50 |
4 |
2.60 |
67.600 |
36 |
|
Diamond M8 |
8 |
5 |
3.20 |
128 |
72 |
|
Round M5 |
3.30 |
3.30 |
2.10 |
22.869 |
20 |
|
Round M6 |
4 |
4 |
2.60 |
41.600 |
32 |
|
Round M8 |
5 |
5 |
3.20 |
80 |
68 |
|
Square M5 |
3.50 |
2.10 |
3 |
22.050 |
231 |
|
Square M6 |
4 |
2.60 |
3.50 |
36.400 |
35 |
|
Square M8 |
5 |
3.50 |
4 |
70 |
68 |
|
Oval M5 |
6 |
3.60 |
2.40 |
51.840 |
29 |
|
Oval M6 |
6.50 |
4 |
2.60 |
67.600 |
3 |
|
Oval M8 |
8 |
2.60 |
3.30 |
68.640 |
64 |
OEM & Custom Manufacturing: Send your 2D DWG or 3D STEP drawings to info@hofengfab.com for a custom quote, or visit Hofengfab to explore our manufacturing capabilities.
CMM Inspection & Quality Control
For precision motor mounting parts, we pay close attention to mounting face flatness, hole positions, and bore alignment. CMM inspection can be used to verify critical dimensions and geometric tolerances against customer drawings, helping ensure a proper fit during assembly.
