IP68 vs. IP69 Waterproof Ratings
| Артикул | IP68 | IP69 |
|---|---|---|
| Защита от пыли | Level 6 – Dust-tight | Level 6 – Dust-tight |
| Защита воды | Long-term immersion (static water) | High-temp & high-pressure water jets |
| Test Conditions | ≥1 m depth, ≥30 min, ambient water | 80℃ water, 80–100 bar, 14–16 L/min, multi-angle spray |
| Приложения | Diving gear, underwater sensors, humid devices | Car wash, food processing, industrial machinery |
| Design Focus | Static sealing (O-rings, compression) | Dynamic sealing + heat-resistant materials |
Which IP Rating Fits Your Needs?
| Scenario | Best Choice | Почему это важно | Typical Products |
|---|---|---|---|
| Everyday use / Rain | IP67 / IP68 | Protects against rain & splashes | Phones, Smartwatches |
| Diving / Underwater | IP68 | Safe for long immersion | Diving gear, Underwater sensors |
| Food & Medical Hygiene | IP69K | Handles hot steam cleaning | Kitchen & Medical equipment |
| Heavy-duty Cleaning | IP69K | Withstands high-pressure jets | Machinery, Car wash panels |
| Marine / Coastal use | IP68 + Anti-corrosion | Extra salt & corrosion resistance | Marine radars, Dockside devices |
Best Material Options for Waterproof Enclosures (IP68/IP69)
| Материал | Key Advantages | Best For |
|---|---|---|
| Нержавеющая сталь 304 | Durable, weather-resistant, cost-effective | Outdoor equipment, EV chargers |
| Stainless Steel 316 | Superior corrosion resistance, seawater & chemical protection | Marine, chemical & IP69 enclosures |
| Aluminum Alloy 6061 | Lightweight, easy to machine, economical | Automotive parts, portable housings |
Quick Tip 💡
-
Choose 316 Stainless Steel for IP69 enclosures (handles high-pressure jets + chemicals).
-
Use Aluminum Alloy with anodizing ≥15 μm for lightweight designs under high-pressure cleaning.
Material Selection Decision Guide
-
First, check the environment:
-
If it’s seawater, high salt spray, or chemicals → go with 316 stainless steel (best balance of cost and performance) or titanium alloy for extreme demands.
-
If it’s freshwater or normal outdoor conditions → choose 304 stainless steel или anodized aluminum alloy.
-
-
Next, consider weight sensitivity:
-
For mobile equipment or aerospace → алюминиевый сплав (6061-T6) is the right choice.
-
For fixed equipment → нержавеющая сталь is preferred (lower cost and easier maintenance).
-
-
Finally, match the IP protection level:
-
IP69 (high-temp, high-pressure cleaning) → 316 stainless steel (corrosion + jet resistance) or surface-treated aluminum alloy (coating must be tested for heat resistance).
-
IP68 (long-term immersion) → 316 stainless steel for marine, 304 stainless steel for freshwater, or titanium alloy for deep-sea.
-
IP65–IP67 (splashing or short-term immersion) → 430 stainless steel (low cost) or 5052 aluminum alloy (lightweight).
-
-
Hofengfab Custom IP-Rated Enclosures
| Характеристика | Highlights |
|---|---|
| Материалы | Stainless steel, Aluminum, Carbon steel, ABS, PC, Polycarbonate |
| Sizes | Any size, fully customized to your drawings |
| Surface Finish | Powder coating, Anodizing, Electroplating, Anti-corrosion |
| Cut-outs & Openings | For cables, connectors, displays, buttons |
| Варианты монтажа | Wall, Floor, Embedded, Pole; supports DIN rails |
| Аксессуары | Seals, Locks, Hinges, Fans, Vent valves |
| Сертификаты | CE, RoHS, UL, IP test reports |
Hofengfab is a leading manufacturer in China offering off-the-shelf electronics enclosures and electrical boxes for OEMs in various industries. Namely, as an IoT network enclosure, Sensor enclosure, Embedded PC case, Instrument enclosure, Industrial control box, Junction box, Distribution box, Audio amplifier chassis, and so on.
Свяжитесь с нами
If you’re looking for reliable IP-rated enclosure solutions, feel free to reach out for a quote, sample, or technical drawings.
We will tailor the most suitable protective enclosure based on your industry requirements and operating environment.
